    JGX-0320D-14.5A Wire Rope Vibration Isolator With Corrosion Resistant Material

    Ask Lasest Price
    Brand Name : Hoan
    Model Number : JGX-0320D-14.5A
    Certification : ISO9001:2015
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 4,pience,7
    Delivery Time : 7
    • Product Details
    • Company Profile

    JGX-0320D-14.5A Wire Rope Vibration Isolator With Corrosion Resistant Material

    JGX-0320 series

    Wire isolation mounts are also named of wire rope isolators, which are comprised of stainless steel stranded cable threaded through aluminum alloy retaining bars that are mounted for effective shock and vibration isolation.

    With their corrosion resistant, all-metal construction, Xi’an Hoan’s wire isolation mounts are environmentally stable,high-performance shock and vibration isolators that are unaffected by temperature extremes, chemicals, oils, ozone and abrasives.

    JGX-0320D-14.5A is the new designed 10 loops 3.2mm diameter model with max static load of 14.5kg, especially used in the precise instruments for the noise attenuation.

    With stainless steel material, this kind wire rope isolator has perfect performance of water-proof, anticorrosion as well as durability.

    The wire isolation mounts are now widely used in the field of military vehicles, armored cars,launcher, highway transportation, marine, shipbuilding, navy, energy, photographic equipment, aerial equipment, communication apparatus, electronic sensing devices, mobile electronic devices, cameras or any other needed working conditions.

    No.Model

    Max Static Load

    (kg)

    Max Defelction

    (mm)

    Kv(vibration)

    (KNm)

    Ks(Shock)

    (KNm)

    1JGX-0320D-22A229.715491
    2JGX-0320D-20A2011.712468
    3JGX-0320D-17A1713.79551
    4JGX-0320D-16A1616.87839
    5JGX-0320D-14.5A14.518.86732
    6JGX-0320D-13.5A13.521.85725
    7JGX-0320D-12A1223.94621

    ApplicationsTypical EquipmentProtection FromOperational Advantages
    Ship board

    Electronics,

    Computers,
    Machinery

    Explosive blast,
    Inherent vibration,

    Storms

    Long life, Maintenance-free,Temperature extremes,Corrosion resistance,All axes protection
    Rough Terrain VehiclsInstrumentation, Generators,
    Electronics
    Rough terrain,
    Poor road conditions,
    Collision
    Long life, Maintenance-free,Temperature extremes, Ozone,Radioactivity, UV Radiation
    AircraftElectronics, ComputersHigh-G maneuvering,
    Hard landings, Turbulent air
    Temperature and altitude extremes, Lightweight
    Shipping ContainersOptics, Instruments, Missiles, Electronics

    Transit, Handling drop,

    Loading/Unloading

    Long life, Maintenance-free,

    Exposure to moisture, Repeated use

    Industrial Equipment

    Centrifuge,

    Dryers,

    Pumps

    Unbalanced dynamic loads,

    Fluid hammer, Inherent vibration, Foundation weakness

    Long life, Maintenance-free,

    Corrosive environments

    Ordnance EquipmentTank artillery, Computer controls, ElectronicsRough terrain, Railroad humping, TransitMaintenance-free, Temperature extremes, Nearby blast
    Medical Equipment

    Mechanical equipment

    necessary for patient care

    Vibration from moving parts, Mobile carts-Transport shockMaintenance-free, No out gassing, Can be sterilized
    Chimneys

    Chimneys, Scrubbers,

    Measuring devices

    Wind causing resonant

    frequencies, Stack gas causing turbulence near scrubber, etc.

    Maintenance-free, Temperature extremes, Corrosive environments

    *The material of the mounting splint *

    Stainless Steel or Aluminum can be selected

    * Surface treatment options for aluminum alloy plywood *

    * White Anodizing: The surface treatment to make the aluminum surface harder than itself. The color of the white anodized aluminum mounting bars keep the same color as the aluminum itself. It is the normal surface treatment of the aluminum mounting bars;
    * Hard Anodizing: The surface treatment to make the aluminum mounting bars much more harder than the white anodized way. The color of the hard anodized aluminum mounting bars is more darker than the white anodizing way. Special use for complex or special requirements of the working conditions of the using of wire rope isolators.
